FOS-RM3 – Overview

RM-3 Rack Mount Speaker System

The Fostex RM-3 is a rackmount stereo audio powered monitor speaker system with both analog and AES/EBU digital audio inputs. The RM-3 is the ideal solution for monitoring needs in various space-challenged environments such as machine rooms, video monitoring, surveillance, control rooms, theme park applications where audio monitoring is needed in a compact environment.

Its list of features include THRU OUT (looping output), XLR/TS 1/4″ phone combination inputs, brightness adjustment of bargraph LED, and auto memory of Input / Output status via rear panel DIP switch. It also has front panel volume control, headphone jack and mute.

Features:
- Rack mount stereo monitor speaker system with built-in 10W+10W D-class amplifier and 110x40mm elongated shape speaker units
- Accepts both Analog input (XLR & 1/4″TS phone) and Digital Input (AES/EBU)
- Headphone out for headphone monitoring. When switching from headphone out to speaker out or vice versa, the output signal fades in to avoid unexpected level difference
- Mute switch works as total mute or -20dB attenuation
- Highly visible 26-dot LED meter (L&R) with 4-step brightness adjustment
- Flexible meter setting for both Analog and Digital inputs such as VU+Peak, VU+Peakhold, Peak+Peakhold and VU only
- Reference level (0dB) is selectable between +4dBu and 0dBu
- Audio characteristics can be selected between the conventional VOICE mode and new MU-SIC mode for wider frequency range music source
Specifications:
- Speaker Section
- Units: 110 x 40mm antimagnetic cone speakers
- Frequency Response: 200Hz – 20kHz
  Amplifier Section
- Rated Output Power: 10W x 2
- Digital Input: XLR-3-31 connector (AES/EBU)
- Sampling Frequency: 44.1kHz to 96kHz
- Analog Inputs: XLR-3-31 connector (balanced)
- Rated Input Level: +4/0dBu
- Input Impedance: 10kΩ or more, 1/4″ Phone jack (unbalanced)
- Rated Input Level: -10/-14dBV
- Input Impedance:10kΩ or more
- Digital THRU: XLR-3-31 connector (AES/EBU)
- Analog THRU: XLR-3-31 / 1/4″ TS phone
- Phones: 1/4″ stereo phones
- Adapted Load Impedance: 16Ω or more
- Maximum Output: 20mW + 20mW (32Ω, 1kHz)
- Level Meter: 26-dot LED x2
- Reference Level: Digital -20dBFS
- Analog XLR +4/9dBu; TS phone -10/-14dBV
- Distortion (T.H.D.): 0.1% or less
  General
- Power Requirement: AC 100V – 240V 50/60Hz
- Power Consumption: 10W (0.5W or less in standby mode)
- Dimensions: 19″ x 1.7″ x 11.2″ (including protruding parts)
- Weight: approx. 7.7lbs
GTIN:

0636827304832
