Sonifex RM-4C8 Reference Monitor - 4 LED/ 8 Inputs & Dual Source Selectors

Sonifex RM-4C8 Reference Monitor - 4 LED/ 8 Inputs & Dual Source Selectors - Image 2

Sonifex RM-4C8 Reference Monitor - 4 LED/ 8 Inputs & Dual Source Selectors - Image 3

Sonifex RM-4C8 Reference Monitor – 4 LED/ 8 Inputs & Dual Source Selectors

Original price was: $396.00.Current price is: $98.99.

SKU: BWFYA 51976586 Categories: Audio Monitoring, Rackmount Audio Monitors

Get the quality you deserve, for less.
Quality You Can Trust
Efficiency meets excellence in customer care.
Safe Payments, Happy Customers

Description
Reviews (0)

RM-4C8 – Overview

With 4 x bright high-resolution 26 segment meter displays and separate left and right source selectors, the RM-4C8 is ideal for monitoring audio channels in an SDI group, or groups of de-embedded
AES/EBU channels.
The RM-4C8 offers the same functionality as the RM-2S4 but with an additional source selector so that any of the 4 channels in the selected group, or bank, can be monitored independently on left and right speakers.
Also, 4 meters are provided so that every channel in the selected group, or bank, can be visually monitored and 4 expansion port groups of 4 channels are allowed, so that all audio channels in an SDI signal can be monitored, using the optional RM-HD1 or RM-HDE1 cards.
The audio inputs on the RM-4C8 are auto-sensing, for digital AES/EBU using the left input XLR, or both XLRs for analogue inputs. The inputs can be used in any combination of analogue or digital.
With full remote control via GPI, RS232 or USB, a 5 band parametric equaliser, 6 front panel modifier buttons and the ability to take the optional 3G/HD/SD-SDI expansion cards, the RM-4C8 is a flexible and versatile monitoring solution.
The same high level of care has been taken in the design of the RM-4C8 as in the RM-2S4 to ensure that it will be the best sounding 1U rack-mount audio monitor that you listen to.

Features:
- 8 Analogue or AES/ EBU Audio
- 5 Audio Modifiers
- Five Band Parametric EQ
- Three-way with stereo mid/ high-frequency drivers & mono low-frequency driver
- Selectable Meter Characteristics
- Status Indicators
- 3G/HD/SD-SDI & Dolby E Options
Specifications:
- Inputs
- Audio Inputs 8 analogue or AES/ EBU digital channels (autoselecting)
- Max level (0dB input gain): +18dBu (analogue)/0dBFS (digital), CMRR: >60dB typical
- Input Impedance: 20k Ohms (analogue) 110 Ohms (digital with termination switchable)
- AES/EBU Sample Rate: 32 to 192kHz, converted internally to 48kHz
- Input Gain: 0, +6, +12 or +18dB digital gain (switchable)
- Selection: 2 x Front panel rotary control with indicator LEDs
- Line Level Outputs
- Audio Outputs: 1 x stereo analogue or AES/EBU digital (switchable)
- Gain re Selected Input: Unity or variable, following volume control (switchable)
- Maximum Output Level: +18dBu (analogue)/0dBFS (digital)
- Output Impedance: 50 Ohms (analogue)/110 Ohms (digital)
- AES/EBU Sample Rate: 48kHz
- Distortion: 0.02% (1kHz, +8dBu output)
- Noise: -84dB RMS, unity gain ref +8dBu output
- Frequency Response: 20Hz-20kHz +0/-0.5dB
- Crosstalk Analogue I/O, ref 0dBu, 1kHz input: -90dB, 10kHz input: -85dB
- User-Variable Equalisation Type: Parametric ,Bands: Five
- Centre Frequency: 200Hz to 18kHz, Bandwidth: 0.25 to 2 octaves, Boost/Cut: ±12dB
- Amplifier/Loudspeakers
- Configuration: Three-way with stereo mid/ high-frequency drivers & mono low-frequency driver
- Power Output: 2 x 5W (HF) + 20W (LF) with protective limiter,
- Crossover: 500Hz (3rd order Butterworth)
- Distortion (HF Outputs): 0.05% (1kHz, 3W output)
- Distortion (LF Output): 0.05% (100Hz, 6W output)
- Noise: More than 80dB below full output
- Peak Acoustic Level: 102dB SPL @ 2ft
- Mains Input: Filtered 3-pin IEC male, continuously rated 85 – 264VAC, 47 – 63Hz, fused, 60W peak, 30W average
- Fuse Rating: Anti-surge fuse 2A 20 x 5mm
